POSYS 1824

The POSYS® 1800 (Designed & Made in Germany) is a state-of-the-art 1 to 4 axes PC104-Bus motion controller supporting multiple host connection modes and motor types.

Communication:

·        PC104-Bus

·        RS232/485

·        CAN

Supported types of motors (ea axis individually configurable):

·        brushed servo motors

·        brushless servo motors (internal and/or external commutation)

·        Microstepping motors

·        Stepping motors

Analogeingänge: 8, Eingangsbereich: 0V – 3V

Uncommitted Digital IOs: 8/8

Committed Digital IOs per Axis: 2x ±Limit, High Speed Latch Input, Reference (Home), 1x AxisIn, 1x AxisOut

Committed Digital IO: 4x AmplifierEnable

Motor command signals:

·        ±10V

·        PWM sign/magnitude

·        PWM 50/50

·        Step & Direction

Update rate: 51,2µs/Axis, 256µs/4 Axes

Encoder input frequency: 8 Mhz



Complies to RoHS specifications.
